The Fenix TK30R rechargeable laser flashlight is one of the tactical flashlights with the longest range in the range. Its white laser light produces an extremely focused beam that is capable of reaching up to 1,500 meters (1,500 yards) and has a light output of up to 500 lumens (ANSI).

The light source is a white laser with LEP (laser excited phosphor) technology, which is known for its use in the automotive industry, especially in the most luxurious cars. Power is supplied by one Li-ion battery type 21700 with a capacity of 6000 mAh (included), which is charged via USB-C connector directly in the flashlight. The charging socket is covered with a screw nut, so it is perfectly protected against water and dirt.

The flashlight is thus fully waterproof and dustproof according to the IP68 standard (tested underwater at a depth of 2 meters). The TK30R features two levels of white light output with a runtime of almost 9 hours, as well as strobe flashing. The flashlight uses a tactical switch with a rotary dial to select between high or low power and lockout.

The flashlight can also be switched directly into strobe mode. The light output is concentrated into a narrow cone, so all the light hits a specific target, making the flashlight ideal for hunting and illuminating distant targets.

All flashlight parameters (luminous flux, battery life, waterproof, range and shockproof) are measured in accordance with ANSI/NEMA FL 1-2009.

Package contents: flashlight, ARB-L21-6000 battery, USB-C charging cable, wrist lanyard, belt pouch, replacement o-ring.

Warranty: five years on the flashlight, two years on the battery.

1. It uses a white laser with LEP (laser excited phosphor) technology with a lifetime of 50000 hours.
2. Electronics with digital power control, protection against reverse battery insertion and protection against too deep battery discharge.
3. Battery stored between two springs - easily withstands recoil when used on the gun.
4. Waterproof and dustproof according to IP68 standard (tested under water at a depth of 2 meters).

• Special optics for a light cone with a range of 1500 meters (600,000 cd).
• Powered by one 21700 6000 mAh Li-ion battery (included).
• Dimensions 18.4 cm (length) x 4 cm (head diameter) x 2.54 cm (body diameter).
• Intelligent overheat protection.
• Flashlight body made of A6061-T6 aircraft hardened aluminum.
• Durable hard scratch resistant surface - Type III hard anodized.
• Shock resistant to falls from a height of 1 meter.
• Highly wear-resistant flat-runner threads.
• Weight 250 grams (including battery).
• Tempered ultra clear glass lens with anti-reflective coating.
• Tactical switch at the end of the flashlight (direct strobe function by holding down the button).
• Rotary switch to select between high and low power and lock control.

Three lighting modes: 500 lumens (3.5 hours) -> 100 lumens (8.8 hours) -> 500 lumen strobe.

Specifications:

Power: 500 lm
Range: 1500 m
Max battery life: 8.8 hrs
Power: 1x 21700, USB rechargeable
Number of modes: 3
Waterproof: IP68 (2m immersion)
Light color: Daylight white (5500-6500K)
Light source: LEP (laser excited phosphor)
Weight: 250 g

Fenix TK30R flashlight controls
There may be an insulating cap on the battery inside the flashlight at the factory. Remove it from the battery pack before first use.
Switching on when the flashlight is unlocked: press the tactical switch on the end of the flashlight for a silent momentary light, when released the light will go out. Fully depress the tactical switch to permanently turn the light on/off.
Switching on if the flashlight is locked: turn the switch from the Lock position to the Low or High position to turn the light on.
Power selection: rotate the switch on the end cap to cycle between the Lock <-> Low <-> High positions to select the desired power or lock (and also turn off) the flashlight.
Strobe activation: with the flashlight unlocked, fully depress the tactical switch for 0.5 seconds to turn on the strobe. Press the tactical switch again briefly to return to steady illumination.
Battery charge indication - the charge indicator is hidden under the protective nut of the charging connector for tactical reasons, so the nut must be unscrewed to check it. The flashlight always indicates the battery charge status three seconds after switching on. Green indicates a sufficient state of charge (100% - 85%), flashing green (85% - 50%), steady red (50% - 25%) and flashing red indicates a critically discharged battery (25% - 1%). If the battery is discharged, the flashlight will automatically switch to lower power modes as the battery is discharged.
Charging the flashlight - Unscrew the protective nut under the head of the flashlight and use the included USB-C cable to plug it into a computer, USB AC adapter or USB car adapter (not included). Alternatively, any cell phone charger with a USB-C connector can be used to charge the flashlight. During charging, the indicator LED opposite the charging connector glows red, and when fully charged it glows green. Charging a fully discharged battery takes approximately 3.5 hours. The Li-ion battery used does not suffer from a memory effect, so the flashlight can be recharged at any time. During charging, the flashlight cannot be switched on.
Intelligent overheating protection - if the temperature of the flashlight rises above 60°C, it automatically starts to reduce the power in gradual steps.

Caution
Use only high quality rechargeable Li-ion batteries type 21700 with protective electronics.
Insert the battery with the positive terminal towards the head of the flashlight.
If the protective rubber rings appear damaged after prolonged use, replace them. The rings should also be lubricated to prevent erosion of the rubber. By following these rules, the flashlight will be properly protected against water.
If the flashlight blinks, does not switch to higher power modes, or does not light up, it may be due to one of the following reasons:
- The battery is almost dead - charge it or replace it.
- The contacts inside the flashlight are dirty - clean them with a cotton swab dipped in alcohol.
- The head, body, or back of the flashlight is loose, tighten them.
