Name: Marlin 5 Gen 3 Fury Red
Brand: TREK
SKU: P1663141
Price: 694.87 EUR
Availability: InStock
Rating: 5 (1 reviews)

/ Cycling / Bikes / Mountain bikes /

TREK Marlin 5 Gen 3 Fury Red

57363, Fury Red

Mountain Bike 2026

1 rating

In stock

at the latest. 12. 2. at your place

694,87 €

You have to choose the color You have to choose the size

Marlin 5 Gen 3 Fury Red

694,87 €

Ready to ride

The bike is always professionally tuned and ready to go.

We will be happy to advise you

We provide expert advice on selection and configuration.

Free warranty inspection

Free warranty inspection after driving 200–500 km

Official TREK Store

Lifetime warranty on the frame, Crash Replacement, Carbon Care.

Detailed description

Components

Specifications

Brand

The Marlin 5 is trail-ready and suitable for everyday adventures, not just on trails. It has a frame that can handle trails with ease, a suspension fork, 9-speed Shimano CUES shifting, and mounts for a rack and kickstand. This makes it the ideal choice for off-road riders and anyone who wants a comfortable and stable commuter bike with the durability of a true mountain bike.

Will my bike have a sloping top tube?
On smaller frames, the top tube slopes down toward the seat tube. This design makes the frame lower, which suits smaller riders who can straddle the bike more comfortably. On larger frames, the top tube is straight, as taller people have longer legs and do not have a problem with straddling.

The right size for every rider
Marlin is available in seven frame sizes for riders of all heights. The size of the Smart Wheels ensures that you will be riding on the fastest possible wheels. The smallest sizes are equipped with short-reach brake levers and narrower handlebars, which provide greater comfort and maneuverability for smaller riders.lt;td style="width: 50%;">

Cutting-edge technology, high value
The Marlin looks good and rides well. It's equipped with features you'd usually find on more expensive bikes. These include an elegant frame with internal gear and brake cable routing, which ensures longer life and protection against the elements.

Shimano CUES
Shimano CUES is the answer to riders' demands for a trouble-free drive with long life and high performance. It is versatile and durable and is designed for a wide range of electric and standard bikes. The CUES drive is equipped with new Shimano LINKGLIDE technology, which significantly extends the life of wear parts such as the chain, cassette, and chainring.

Shimano LINKGLIDE
LINKGLIDE technology, characterized by incredible durability and smooth, crisp shifting, guarantees a pleasant riding experience. Available exclusively with Shimano CUES drivetrains.

Get better pedals and fall even more in love with your bike
Pedals are two of the five points of contact that connect you to your bike, and although this bike comes with pedals installed, you can significantly improve your ride quality by upgrading to pedals that enhance control and grip. Browse our pedal guide to choose the ones that suit your riding style. We recommend flat pedals for their versatility.

The goods are in the following categories:

MARLIN mountain bikes TREK all

In our e shop you will find cycling equipment from TREK such as cycling jerseys, kneesocks, trunks, cycling computers, bike bottles, rain jackets and thousands of other small items. In bikes we offer a comprehensive range which includes mountain bikes, trekking bikes, bmx bikes and kids bikes.

TREK is headquartered in Waterloo, Wisconsin. The family-owned business was founded by Richard Burke in 1976, starting out in a small steel bicycle factory with just five employees. Within a few short years, the company caught on to bicycle trends and continued to grow. In the early 1990s, it began producing bicycles in a then-new material - Carbone. Today, TREK sets the trends in bicycle development and is also considered a leader in the processing of Carbone. Its proprietary processing technology, called OCLV, has been applied in production with many innovations for more than 17 years. TREK bikes have celebrated success at major world races and have been associated with names such as Lance Armstrong, Alberto Contador, Chris Lieto, Roland Green, Chris Eatough, Andrew Shandro and Travis Brown. TREK is a premium brand you can always rely on.

colour: Red

Suspension: Front suspension

Material: Aluminium

Travel: 100-120 mm

Model year: 2026

Code:57363, Fury Red

Brand: TREK

Frame
*Frame	Size: XS Alpha Silver aluminum, curved top tube, internal derailleur cable routing and telescopic seat post, rack and kickstand mount, ThruSkew 135 x 5 mm.
*Frame	Size: S, M, ML, L, XL, XXL Alpha Silver aluminum, internal derailleur and dropper seatpost cable routing, rack and kickstand mount, ThruSkew 135 x 5 mm.
*Fork	Size: XS SR Suntour XCT 30, coil spring, stiffness adjustment, hydraulic lockout, 42 mm offset for 27.5" wheels, 100 mm quick release, 80 mm travel.
	Size: S SR Suntour XCT 30, coil spring, stiffness adjustment, hydraulic lockout, 42 mm offset for 27.5" wheels, 100 mm quick release, 100 mm travel.
	Size: M, ML, L, XL, XXL SR Suntour XCT 30, coil spring, stiffness adjustment, hydraulic lockout, 42 mm offset for 29-inch wheels, 100 mm quick release, 100 mm travel.
Wheels-rims
Front hub	Formula DC-20, alloy, 6 bolts, quick release 5 x 100 mm.
Front quick release	Trek Thru-Skew axle
Rear hub	Formula DC-22, alloy, 6 bolts, Shimano 8/9/10 Freehub, quick release 135 x 5 mm.
Rear quick release	173 x 5 mm quick release
Rim	Bontrager Connection, double wall, 32 holes, 20 mm width, Schrader valve.
Spokes	14 g, stainless steel, black.
*Tire	Size: XS, S. Bontrager Montrose Comp, wire bead, 30 tpi, 27.5 x 2.40 inches.
*Tire	Size: M, ML, L, XL, XXL Bontrager Montrose Comp, wire bead, 30 tpi, 29 x 2.40 inches.
Drivetrain
Shifters	Shimano U4000, 9 speeds.
Rear derailleur	Shimano CUES U4000.
*Crank	Size: XS, S, M, ML. Shimano CUES U4001, 32 teeth, chainline 52 mm, length 170 mm.
*Crank	Size: L, XL, XXL Shimano CUES U4001, 32 teeth, chainline 52 mm, length 175 mm.
Bottom bracket	Shimano, 73 mm, threaded cartridge, 122.5 mm axle.
Cassette	Shimano LINKGLIDE LG300, 11-46, 9 speeds.
Chain	Shimano LG500.
Pedal	VP-536, nylon platform
Components
Saddle	Bontrager Verse Short, stainless steel rails.
*Seatpost	Size: XS, S, M Alloy, Bontrager, 31.6 mm, 12 mm offset, 330 mm length.
*Seatpost	Size: ML, L, XL, XXL Alloy, Bontrager, 31.6 mm, 12 mm offset, 400 mm length.
*Handlebars	Size: XS Alloy, Bontrager, 31.8 mm, 5 mm bend, width 690 mm.
	Size: S Alloy, Bontrager, 31.8 mm, 15 mm rise, width 720 mm.
	Size: M, ML, L, XL, XXL Alloy, Bontrager, 31.8 mm, 15 mm bend, 750 mm width.p>
Grips	Trek Line Comp, nylon lock
*Stem	Size: XS , S Bontrager Comp, 31.8 mm clamp, 7 degrees, 35 mm length
	Size: M, ML, L Bontrager Comp, 31.8 mm clamp, Blendr compatible, 7 degrees, 50 mm length
	Size: XL Bontrager Comp, 31.8 mm clamp, Blendr compatible, 7 degrees, 60 mm length
	Size: XXL Bontrager Comp, 31.8 mm clamp, Blendr compatible, 7 degrees, 70 mm length
Headset	Semi-integrated, 1-1/8 inch.
Brake	Shimano MT200 hydraulic disc version
*Brake rotor	Size: XS, S, M, ML, L, XL, XXL Shimano RT26, 6 holes, 160 mm.
*Brake rotor	Size: M, ML, L, XL, XXL Shimano RT26, 6 holes, 180 mm.
Brake set	Shimano MT200 hydraulic disc version
Weight
Weight	M - 15.10 kg / 33.29 lbs
Weight limit	The bike has a maximum total weight limit (combined weight of bike, rider, and cargo) of 136 kg (300 lbs).
